CDM-POROTRACK


The CDM-POROTRACK? is a poured elastomer solution that is used to provide vibration isolation for embedded track. The rail is continuously supported horizontally and vertically.

CDM-POROTRACK? can be used to support rails for heavy as well as light rail-transport, level crossings and turnouts, rail systems on bridges, tunnels etc…

There are two basic setups of CDM-POROTRACK? with CDM-FLEXIWEB resin-bonded rubber filling, or with PVC tubes (possible integration of cabling).



CDM-FLEXWEB
Silicon watertight joint


Poured material

Adjustment wedge
CDM-SRS railstrip


resin-bonded rubber

adjustment plate

with PVC tubes

view on installation with PVC tubes
1 CDM-POROTRACK? allows the vibration isolation performance to be tuned by changing the stiffness of the CDMISO- SRS resilient railstrip under the rail

2 Considerable reduction of the re-radiated noise

3 The continuous support of the rail, combined with the CDMISO- POROTRACK? system guarantees a uniform elasticy in the length direction of the track, thus prolonging the life of the rail and minimising corrugation

4 Constant geometry, even after many years of intensive use

5 Considerable savings due to reduced construction height and weight (e.g. tunnels and bridges)

6 Low maintenance
